Type D7 Xray Crawler Industrial X Ray Film HUATEC

  • Type D7 Xray Crawler Industrial X Ray Film HUATEC
  • Type D7 Xray Crawler Industrial X Ray Film HUATEC
  • Type D7 Xray Crawler Industrial X Ray Film HUATEC
  • Type D7 Xray Crawler Industrial X Ray Film HUATEC
Место происхождения Пекин
Фирменное наименование HUATEC
Сертификация ISO, CE, GOST
Номер модели Отражающая пленка D7
Количество мин заказа 500 шт.
Упаковывая детали Стандартный экспортный пакет
Время доставки 1-4days
Условия оплаты T/T, PayPal, Western Union
Поставка способности 5000000 штук в месяц

Свяжитесь со мной для бесплатных образцов и купонов.

Ватсап:0086 18588475571

WeChat: 0086 18588475571

Скайп: sales10@aixton.com

Если у вас есть какие-либо проблемы, мы предоставляем круглосуточную онлайн-помощь.

x
Подробная информация о продукте
Материал ПЭТ Тип Д7
Имя Промышленная рентгеновская пленка Размер Любой размер
Пакет Упаковка вакуума
Выделить

xray crawler industrial x ray film

,

industrial x ray film d7

,

industrial x ray film HUATEC
Оставьте сообщение
Характер продукции

High Sensitivity, High Contrast, High Definition Industrial X-Ray Film D7 X-Ray Crawler



Product name and model specification

Model Specification

D4,D4-D,H4,LA400,D5,D5-D,

D7,D7-D,H7,H7-D

 356mm×432mm(14in.×17in.),305mm×381mm(12in.×15in.),260mm×360mm (10in. ×14in.),70mm×300mm,80mm×150mm,80mm×240mm,80mm×300mm,80mm×360mm, 100mm×356mm,195mm×275mm,70mm×200m,80mm×100m,80mm×200m

Other specifications and packing capacity can also be provided according to customer requirements.



Features and uses

Industrial X-ray film is a kind of high resolution and high image resolution film which is widely used in nondestructive flaw detection. The film has high sensitivity, high contrast, high definition,



It can be directly or with lead sensitization screen for X or γ ray exposure. It is suitable for electronic components, synthetic materials, casting and casting, welding, etc.



NDT testing for shipbuilding, national defense and nuclear industry, aerospace and aviation industry, etc. Using blue polyester sheet base, two sides coated with emulsion layer, layer and



Protective layer. This film has rich layers, high image resolution and good definition. This film can be processed at room temperature, also can be processed by high temperature machine.



Features and uses

Type D7 Xray Crawler Industrial X Ray Film HUATEC 0　 GB/T19348.1 EN 584.1 ASTME 1815-08 ISO 11699-1
D4,D4-D,H4 C3 C3 Ⅰ C3
D5,D5-D C4 C4 Ⅰ C4
D7,LA400,D7-D,H7,H7-D C5 C5 Ⅱ C5



Product performance

Name of index unit D4,D4-D H4 LA400 D5,D5-D D7,D7-D,H7,H7-D
Density of fog --　 ≤0.10 ≤0.10 ≤0.10 ≤0.10 ≤0.12
Contrast factor “r” --　 ≥4.0 ≥3.0 ≥3.2 ≥4.0 ≥3.5
ISO “S” --　 ≥1.5 ≥1.0 ≥0.6 ≥1.5 ≥2.0
Alkali soluble time Minutes ≥10
Scratch resistance in processing N ≥0.8

Safety lighting and washing processing

The safety operating light in the darkroom of this film is a crimson safety light with a 15W bulb. When the film is used for unsealing, the lamp distance is generally above 1.2 meters. Cumulative illumination time



No more than 40 minutes. The exposed sample should be flushed within 2h. The washing process is shown in the table below.

Flush the way Other countries Temperature / ℃ Development time /min Fixed time /min Dry / ℃ transshipment

ml/m2
Manual D-19b 20±0.5 5±1 10 Natural drying 300
Machine wash G-30 29±1 1.5～2 2 45～55





Applications :
This film is suitable for different NDT applications such as: medium thickness heavy metals and alloys, fairly thick light metals and alloys, and also suitable for NDT of heavy metal parts having thick section when exposed with high-energy radiation. The film is especially suited to high temperature automatic processing. This product is compatible with international norms.

  • Welding and casting
  • Defense industry
  • Aerospace and aircraft industry
  • Composite materials
  • Multiple film techniques
